| QDPPM42-160-G12/WD-_HB0 | 12 VDC | Connector socket EN 175301-803 / ISO 4400 | NBR | Screw plug |
| QDPPM42-160-G12/WD-_HC8.5 | 12 VDC | Connector socket EN 175301-803 / ISO 4400 | NBR | Manual override |
| QDPPM42-160-G12/WD-D1HB0 | 12 VDC | Connector socket EN 175301-803 / ISO 4400 | FKM (Viton) | Screw plug |
| QDPPM42-160-G12/WD-D1HC8.5 | 12 VDC | Connector socket EN 175301-803 / ISO 4400 | FKM (Viton) | Manual override |
| QDPPM42-160-G12/WJ-_HB0 | 12 VDC | Connector socket AMP Junior-Timer | NBR | Screw plug |
| QDPPM42-160-G12/WJ-_HC8.5 | 12 VDC | Connector socket AMP Junior-Timer | NBR | Manual override |
| QDPPM42-160-G12/WJ-D1HB0 | 12 VDC | Connector socket AMP Junior-Timer | FKM (Viton) | Screw plug |
| QDPPM42-160-G12/WJ-D1HC8.5 | 12 VDC | Connector socket AMP Junior-Timer | FKM (Viton) | Manual override |
| QDPPM42-160-G12/WG-_HB0 | 12 VDC | Connector Deutsch DT04-2P | NBR | Screw plug |
| QDPPM42-160-G12/WG-_HC8.5 | 12 VDC | Connector Deutsch DT04-2P | NBR | Manual override |
| QDPPM42-160-G12/WG-D1HB0 | 12 VDC | Connector Deutsch DT04-2P | FKM (Viton) | Screw plug |
| QDPPM42-160-G12/WG-D1HC8.5 | 12 VDC | Connector Deutsch DT04-2P | FKM (Viton) | Manual override |
| QDPPM42-160-G24/WD-_HB0 | 24 VDC | Connector socket EN 175301-803 / ISO 4400 | NBR | Screw plug |
| QDPPM42-160-G24/WD-_HC8.5 | 24 VDC | Connector socket EN 175301-803 / ISO 4400 | NBR | Manual override |
| QDPPM42-160-G24/WD-D1HB0 | 24 VDC | Connector socket EN 175301-803 / ISO 4400 | FKM (Viton) | Screw plug |
| QDPPM42-160-G24/WD-D1HC8.5 | 24 VDC | Connector socket EN 175301-803 / ISO 4400 | FKM (Viton) | Manual override |
| QDPPM42-160-G24/WJ-_HB0 | 24 VDC | Connector socket AMP Junior-Timer | NBR | Screw plug |
| QDPPM42-160-G24/WJ-_HC8.5 | 24 VDC | Connector socket AMP Junior-Timer | NBR | Manual override |
| QDPPM42-160-G24/WJ-D1HB0 | 24 VDC | Connector socket AMP Junior-Timer | FKM (Viton) | Screw plug |
| QDPPM42-160-G24/WJ-D1HC8.5 | 24 VDC | Connector socket AMP Junior-Timer | FKM (Viton) | Manual override |
| QDPPM42-160-G24/WG-_HB0 | 24 VDC | Connector Deutsch DT04-2P | NBR | Screw plug |
| QDPPM42-160-G24/WG-_HC8.5 | 24 VDC | Connector Deutsch DT04-2P | NBR | Manual override |
| QDPPM42-160-G24/WG-D1HB0 | 24 VDC | Connector Deutsch DT04-2P | FKM (Viton) | Screw plug |
| QDPPM42-160-G24/WG-D1HC8.5 | 24 VDC | Connector Deutsch DT04-2P | FKM (Viton) | Manual override |
| QDPPM42-160-X5/WD-_HB0 | without coil | Connector socket EN 175301-803 / ISO 4400 | NBR | Screw plug |
| QDPPM42-160-X5/WD-_HC8.5 | without coil | Connector socket EN 175301-803 / ISO 4400 | NBR | Manual override |
| QDPPM42-160-X5/WD-D1HB0 | without coil | Connector socket EN 175301-803 / ISO 4400 | FKM (Viton) | Screw plug |
| QDPPM42-160-X5/WD-D1HC8.5 | without coil | Connector socket EN 175301-803 / ISO 4400 | FKM (Viton) | Manual override |
| QDPPM42-160-X5/WJ-_HB0 | without coil | Connector socket AMP Junior-Timer | NBR | Screw plug |
| QDPPM42-160-X5/WJ-_HC8.5 | without coil | Connector socket AMP Junior-Timer | NBR | Manual override |
| QDPPM42-160-X5/WJ-D1HB0 | without coil | Connector socket AMP Junior-Timer | FKM (Viton) | Screw plug |
| QDPPM42-160-X5/WJ-D1HC8.5 | without coil | Connector socket AMP Junior-Timer | FKM (Viton) | Manual override |
| QDPPM42-160-X5/WG-_HB0 | without coil | Connector Deutsch DT04-2P | NBR | Screw plug |
| QDPPM42-160-X5/WG-_HC8.5 | without coil | Connector Deutsch DT04-2P | NBR | Manual override |
| QDPPM42-160-X5/WG-D1HB0 | without coil | Connector Deutsch DT04-2P | FKM (Viton) | Screw plug |
| QDPPM42-160-X5/WG-D1HC8.5 | without coil | Connector Deutsch DT04-2P | FKM (Viton) | Manual override |
