BDBPM22 直动式防爆比例减压插装阀 # WANDFLUH // 万福乐


BDBPM22

直动式防爆比例减压插装阀Ex d II C

Description

直接控制比例泄压阀，采用螺纹插装式设计，符合 ISO 7789 标准。 采用压差原理，流量大，调节灵敏。当达到比例电磁阀设定的工作压力时，阀门打开并将保护管路连接至油箱的回油管路。T (2) 的背压影响 P (1) 的压力。Wandfluh 比例放大器可用于控制（见寄存器 1.13）。防火封装的防爆电磁线圈 防爆电磁线圈可防止内部爆炸逸散到外部和可燃表面温度。

Application

这些阀门适用于潜在爆炸性气体环境、地面和采矿环境。阀门的 阀门的电气远程控制与过程控制相结合，可实现可重复过程的经济型解决方案。螺纹插装阀非常适合于以下场合 螺纹插装阀非常适合安装在控制块中，并可安装在夹层板（垂直连接）和法兰板中（本手册中的相应数据表）。 中的相应数据表）。可提供在钢块和铝块上制造插装孔的阶梯工具（租用或购买）。请参见表 2.13 中的数据表。

Key facts

比例泄压阀芯

  • 直接控制

  • Qmax = 25 升/分钟

  • pmax = 400 bar

  • pNmax = 350 bar

WandfluhBDBPM22-100-G24/L15609.3353BDBPM22-100/L15U= 24 VDC
WandfluhBDBPM22-100-X5/L15609.3417BDBPM22-100/L15无线圈
WandfluhBDBPM22-100-G24/L15/MA609.3749BDBPM22-100/L15/MAU= 24 VDC
WandfluhBDBPM22-100-G24/L15/UL-M187609.3653BDBPM22-100/L15/UL-M187U= 24 VDC
WandfluhBDBPM22-100-G24/L15-D1609.3411BDBPM22-100/L15-D1U= 24 VDC
WandfluhBDBPM22-100-G24/L15-M187609.3686BDBPM22-100/L15-M187U= 24 VDC
WandfluhBDBPM22-100-G24/L15-M248609.3752BDBPM22-100/L15-M248U= 24 VDC
WandfluhBDBPM22-160-G24/L9609.3403BDBPM22-160/L9U= 24 VDC
WandfluhBDBPM22-20-G24/L15609.3345BDBPM22-20/L15U= 24 VDC
WandfluhBDBPM22-20-G24/L15/UL-M187609.3656BDBPM22-20/L15/UL-M187U= 24 VDC
WandfluhBDBPM22-20-G24/L15-D1609.3277BDBPM22-20/L15-D1U= 24 VDC
WandfluhBDBPM22-200-G24/L15609.3314BDBPM22-200/L15U= 24 VDC
WandfluhBDBPM22-200-X5/L15609.3496BDBPM22-200/L15无线圈
WandfluhBDBPM22-200-G24/L15/MA609.3768BDBPM22-200/L15/MAU= 24 VDC
WandfluhBDBPM22-200-G24/L15/UL-M187609.3706BDBPM22-200/L15/UL-M187U= 24 VDC
WandfluhBDBPM22-200-G24/L15-D1609.3346BDBPM22-200/L15-D1U= 24 VDC
WandfluhBDBPM22-200-G24/L15-D1M248609.3756BDBPM22-200/L15-D1M248U= 24 VDC
WandfluhBDBPM22-200-G24/L15-M248609.3595BDBPM22-200/L15-M248U= 24 VDC
WandfluhBDBPM22-200-y-G24/L15-Z604609.36BDBPM22-200-y/L15-Z604U= 24 VDC
WandfluhBDBPM22-250-X5/L9609.3703BDBPM22-250/L9无线圈
WandfluhBDBPM22-250-G24/L9-D1609.3361BDBPM22-250/L9-D1U= 24 VDC
WandfluhBDBPM22-275-G24/L15609.3604BDBPM22-275/L15U= 24 VDC
WandfluhBDBPM22-275-X5/L15609.3645BDBPM22-275/L15无线圈
WandfluhBDBPM22-275-G24/L15/MA609.3663BDBPM22-275/L15/MAU= 24 VDC
WandfluhBDBPM22-275-G24/L15-M248609.3644BDBPM22-275/L15-M248U= 24 VDC
WandfluhBDBPM22-275-y-G24/L15-Z604609.365BDBPM22-275-y/L15-Z604U= 24 VDC
WandfluhBDBPM22-280-G12/L9609.3476BDBPM22-280/L9U= 12 VDC
WandfluhBDBPM22-280-G24/L9609.3398BDBPM22-280/L9U= 24 VDC
WandfluhBDBPM22-280-X5/L9609.3621BDBPM22-280/L9无线圈
WandfluhBDBPM22-315-G12/L15609.3371BDBPM22-315/L15U= 12 VDC
WandfluhBDBPM22-315-G24/L15609.333BDBPM22-315/L15U= 24 VDC
WandfluhBDBPM22-315-X5/L15609.3376BDBPM22-315/L15无线圈
WandfluhBDBPM22-315-G24/L15/MA609.3766BDBPM22-315/L15/MAU= 24 VDC
WandfluhBDBPM22-315-G24/L15-D1609.3739BDBPM22-315/L15-D1U= 24 VDC
WandfluhBDBPM22-350-G12/L15609.3453BDBPM22-350/L15U= 12 VDC
WandfluhBDBPM22-350-G24/L15609.3336BDBPM22-350/L15U= 24 VDC
WandfluhBDBPM22-350-X5/L15609.3405BDBPM22-350/L15无线圈
WandfluhBDBPM22-350-G24/L15/MA609.366BDBPM22-350/L15/MAU= 24 VDC
WandfluhBDBPM22-350-G24/L15/UL-M187609.3693BDBPM22-350/L15/UL-M187U= 24 VDC
WandfluhBDBPM22-350-G24/L15-D1609.3362BDBPM22-350/L15-D1U= 24 VDC
WandfluhBDBPM22-350-G24/L21609.359BDBPM22-350/L21U= 24 VDC
WandfluhBDBPM22-350-y-G24/L15/UL-M187Z604609.3672BDBPM22-350-y/L15/UL-M187Z604U= 24 VDC
WandfluhBDBPM22-350-y-G12/L15-M248609.378BDBPM22-350-y/L15-M248U= 12 VDC
WandfluhBDBPM22-350-y-G12/L15-Z604609.3464BDBPM22-350-y/L15-Z604U= 12 VDC
WandfluhBDBPM22-350-y-G24/L15-Z604609.3538BDBPM22-350-y/L15-Z604U= 24 VDC
WandfluhBDBPM22-63-G24/L15609.3534BDBPM22-63/L15U= 24 VDC
WandfluhBDBPM22-63-G24/L15-M248609.3687BDBPM22-63/L15-M248U= 24 VDC
WandfluhBDBPM22-80-G24/L9609.328BDBPM22-80/L9U= 24 VDC
